Pressure Vessels
Low Pressure Vessels

INTRODUCTION

The benefits of continually over feeding the evaporators of a multi-circuited refrigeration system are popular world over amongst industrial users of ammonia refrigerant. Pumped liquid ammonia is the preferred method of evaporator feed because of its simplicity and high performance. By completely wetting the inner surface of evaporator coils with an excessive flow of subcooled liquid refrigerant maximum heat transfer rates are achieved, resulting in higher system efficiency and reduced operating cost.

LOW PRESSURE VESSELS

Table for Low Pressure Receiver Selection :

Capacity : Tons of Refrigeration

Vessel Dia
Inches

Vessel Length
Feet

Evaporation Temperature (F)



Based on two stage compressors

Based on single stage compressors



(-) 50

(-) 40

(-) 30

(-) 20

(-) 10

0

(-) 10

20

30

40

50

20

10

10

12

14

17

19

21

23

26

28

30

32

24

10

24

28

34

40

44

49

54

60

66

72

78

30

10

57

70

85

101

111

123

135

146

162

175

188

36

10

109

130

156

183

203

223

246

272

302

331

360

42

10

175

209

251

295

327

360

397

436

488

534

580

48

12

254

304

365

429

475

526

580

640

713

776

839

54

12

328

396

477

561

622

687

756

837

928

1022

1117

60

12

416

498

601

710

790

871

963

1070

1181

1294

1404

The data given in the table is just indicative for details please Contact Us

Metalex Re-circulation systems follow th Witt (Germany) designs to ensure trouble free, no turbulence flow of liquid to the evaporators through refrigerant pumps and also prevents the liquid getting sucked to the compressor thus protecting the compressors of liquid hammer.

  • Each LP receiver is supplied with Metalex make high pressure reflex type gauge glass, high and low side liquid floats, Isolation Valves, Duel Safety Valve, Drain Valve and Purge Valve. The receiver is mounted on a sturdy steel structure.
  • Inter connecting piping on the skid.
  • Working Pressure 6 Kg / CM2.
  • Test Pressure 21 Kg / CM2.
